To Assure strict compliance with our customer’s specifications, Asquare Enterprise utilize data collection devices to enable our operator to maintain process control. MFPL utilize complete Chemical, Metallurgical, and Physical Test facility to perform complete failure analysis with the help of Spectro meter, Zoom Stereo Micro Scope, High resolution Inverted Microscope, Optical Hardness Tester, Profile Projector, Crack Detector, Eddy Current Digital Multifact Hardness, Mix-up Metal Sorter, Ultrasonic Tester, Alloy Analyzer, Contracer for Contour Measurement & CMM.

Digital U.T. Machine (Modsonic)

Contracer (Mitutoyo)

Alloy Analyzer (Innov-X System)

CMM (Mitutoyo)

Grade:

SAE 52100 / 100cr6 manufactured through Electric Are Furnace, Ladle Refining Furnace & Vacuum Degassed (must not be ‘Ca’-‘Si’ deoxidized) and equal or less than C2R2S2 according to Plate I of ASTM E-381.

Micro Structure:

Completely spheroidize Cemmentite in Ferrite Matrix with Uniform distributed Carbides as per size CG 2.1 to 2.3 and Perlite amount = 3.0 according to SEP 1520-98.

	Chemical Composition :
C Si Mn P S Cr Ni Mo Min. 0.93 0.15 0.25 -- -- 1.35 -- -- Max. 1.05 0.35 0.45 0.025 0.015 1.60 0.25 0.10   Cu As Sn Sb Pb Al Ca Ti O2 Min. -- -- -- -- -- -- -- -- -- Max. 0.30 0.04 0.03 0.005 0.002 0.050 10 ppm 30 ppm 15 ppm

Micro Inclusions :
	Equal or Less than according to Plate I-r of ASTM E-45 i.e.   A B C D T 2.0 1.5 0.0 1.0 H 1.5 0.5 0.0 0.5

Micro Structure

Carbide Network
MAX CN 4.3/CN 5.3 according to SEP 1520-98.
Carbide Streaks
MAX CZ 6.3/CZ 7.3 according to SEP 1520-98.
